BRAND: GMS

PRODUCT CODE: STRAIGHT 12

• Straightening of diameters up to 12 mm
• Cut in the desired ranges with the variable measurement system
• Stripper: 2.5 tons of wire rod load capacity
• Digital control
• Strength of steel:

45 kg / mm²   1 Piece / Ø12
65 kg / mm²   1 Piece / Ø10
85 kg / mm²   1 Piece / Ø8

• Machine:         Width 106 cm / Length 246 cm / Height 110 cm / Weight: 875 kg
• Unwinder:       Width 192 cm / Length 200 cm / Height 250 cm / Weight: 430 kg
• Bar collector:  Width 80 cm / Length 300 cm / Height 80 cm / Weight: 195 kg
• Rotation: 1450 rpm
• Frequency: 50 Hz
• Voltage: 380V
• Straightening motor power: 4 kW
• Motor cutting power: 4 kW
• Launch motor power: 4 kW
• Machine capacity: 6-12 mm
• Machine capacity: 57 m / sec
